Electric Winch 9500lbs Winch Hoist Car Tools Lifting Traction Wire Rope Fiber Rope

Product Properties

Place of origin： Taizhou, Zhejiang    Whether imported or not

Order No. ：BLD-9500                       Brand： BLD

Model ：BLD-9500                             Item No. ：BLD-9500

Motor ：12V/24V                               Processing customization：NO

Voltage ：12V/24V                             Pulling force ：4300kgs

Type ：electric                                    Overall dimension： 610×350×270mm

Rope ：length 26(m)                          Weight：35(kg)

Motor power： 12V/24V                    Working load ：9500lbs

Tooth speed ratio： 265:1                  Breaking strength ：9500lbs

Wire rope diameter and length： Φ9.1mmX26m           Size：610×350×270mm

Material steel                                   Net weight： 35

Whether cross-border export exclusive source ：No

Description

Rated line pull:9500LBS (4309kgs) single line
Motor:4.4kw/6hp, series wound
Control:Remote switch, 9.8ft(3.0m)lead
Gear train:3 Stage Planetary
Gear reduction ratio:265:1
Clutch:Sliding Ring Gear
Braking action:Automatic In-The-Drum
Drum size :Φ2.5"(64)mm×(8.8")223.5mm
Cable:Φ9.1mmX26m
Overall dimensions:529mm×160mm×217mm
Mounting bolt pattern:255mm×114mm Φ11
Weight:N.W.33kg G.W.35Kg
Packing size:610×350×270mm
