Bld Brand Quick Handle Quick Removal Handle Hand Winch Hand Crank Boat 3000 Lbs.

bld brand Quick Handle Quick Removal Handle Hand Winch Hand Crank Boat 3000 lbs.

Properties

Place of origin: Taizhou, Zhejiang      Whether imported or not:NO

Order No.: Quick Handle 3000lbs      Brand:BLD

Model No. :Quick Handle 3000lbs     Item No. Quick Handle :3000lbs

Motor :without motor Processing      customization :NO

Voltage:No voltage                             Pulling force :3000lbs

Type :manual                                      Overall Dimension:57.5X33.5X27

Rope length :10(m)                            Weight:3.8(kg)

Motor power:no motor                     Working load:3000lbs

Tooth speed ratio :4:1/8:1                  Breaking strength: 2045kg

Wire rope diameter and length: 6.0mm

Size:57.5X33.5X27

Material :A36 steel                             Net weight: 3.8kg

Whether cross-border export exclusive source :No

Description

Adopting high quality steel and exquisite craftsmanship, the gears work together seamlessly.

The high temperature quenching and heat treatment bring the gear set and pawl toughness and wear resistance, perfect plating process brings the surface of the silky smooth touch, the achievement of the top quality of Belite winch.

Fixed port on the bottom of the winch, can be bolted anywhere for towing tasks

棘爪和齿轮的咬合和刹车

抽出绞绳的方法




BLD 倍力得 绞盘 玉环健速优质品牌

Winch use precautions:

1, winch is strictly prohibited to carry people!

2, winch is strictly prohibited overload use!

3, winch work is prohibited contact with the wire rope, drum and gear disk. At work, it is best to cover the wire rope on a piece of light fabric, in order to prevent the sudden breakage of the wire rope because of the huge retraction force injuries.

4、When working, at least 5 turns of wire rope should be guaranteed on the drum to keep the wire rope from slipping.

5、When working, we should try to keep the wire rope perpendicular to the drum to prevent the wire rope from wearing out at the edge of the hub!

6、When pulling a heavy load, it is recommended to use a movable pulley to relieve the hand cranking force!
